RPB60 Shearer

SHEARER ON FLOOR
RPB60

Introduction

The narrow web cutter loader RPB60 is designed to work in low and steeply sloping seam of 0.38-0.85 m height and 35-85º dip angle

RPB60 can be used in potentially explosive atmosphere as Group I category M2 equipment and fulfill all the relevant requirements of Explosive Atmospheres Directive 94/9/EC(ATEX)



Click on image to enlarge

Characteristics



Drum diameter , mm 440 380
Thickness of the seam, m. 0,44 – 0,85 0,38-0,82
Dip angle of the seam, º 35 - 85 35 - 85
Maximum Coal strength, Kg/cm² 300 300
Maximum Longwall panel length 160 160
Supporting method Individual props or roof supports Individual props or roof supports
Coal loading Gravity Gravity





pdfDownload product full description PDF
